Intermittent Bonded Ribbon Production Line Guide
At set intervals, an intermittent bonded ribbon production line joins fiber subunits. Fibers remain organized for mass-fusion splicing, while the ribbon can fold into a compact cable shape. The design enables flexible ribbon cable production without compromising efficient fiber handling.
Some processes deposit bonding material before the subunit coating cures. Diffusion can occur across the shared interface before the materials cure together. Prysmian’s FlexRibbon technology provides one commercial example, and the company dates its original design to 2018. These methods illustrate how optical fiber ribbon manufacturing and fiber optic bonding operate together.
Fiber Cable Sheathing Line Fibers In Stainless Steel Tube Fiber Coloring Machine
Understanding What An Intermittent Bonded Fiber Ribbon Is
An intermittent bonded fiber ribbon organizes optical fibers into small subunits. Although they remain organized for splicing, the subunits can change their shape to fit within a cable.
The Arrangement Of Fiber Subunits And Intermittent Bonds
Each adjacent pair or group of fibers is held together by a coating. These optical fiber subunits connect to neighboring subunits at separated bond points rather than along their full length. A 12-fiber design may include six two-fiber subunits. Configurations can contain 4 to 36 fibers, with bonds spaced from 10 to 1,000 millimeters apart.
Intermittent Bonded Ribbon Production Line
Differences Between Rollable Ribbons And Conventional Flat Ribbons
A conventional flat ribbon holds its fibers in a single fixed plane. Between bonds, a rollable fiber ribbon can fold without losing the fiber alignment needed for mass-fusion splicing. Prysmian’s FlexRibbon uses small bonding points to permit bending and folding.
Why Flexible Ribbons Support Compact, High-Density Cables
Ribbon flexibility reduces the space it occupies inside a high-density fiber cable. Cable designers can therefore accommodate more fibers in a compact structure without sacrificing an organized fiber layout.
Process And Equipment For An Intermittent Bonded Ribbon Production Line
The intermittent bonded ribbon production process places optical fibers side by side along the ribbon’s length. A first material coats groups of two or more fibers to create subunits. Neighboring subunits are joined at separate points with a second material, leaving flexible sections between bonds.
Arrange Adjacent Optical Fibers Into Subunits
Fibers are positioned beside one another according to the planned ribbon layout. Each selected group becomes a subunit when the first coating material encases and holds its fibers together.
Apply Subunit Coating And Intermittent Bonding Material
The subunits are created by fiber ribbon coating. Bonding material is applied by a discrete coating applicator between neighboring subunits at spaced intervals, not continuously along their full length.
Use Wet-On-Wet Application To Form Diffusion Zones
Wet-on-wet bonding involves depositing the bonding material before the subunit coating has cured. The materials diffuse across their shared interface to form a diffusion zone.
Cure The Subunit Coating And Bonds Together
A single curing step sets both the subunit coating and the intermittent bonds. Although optical fiber ribbon equipment is used for these operations, the complete equipment list, line speed, and production capacity are not provided.
| Production Stage | Material Or Action | Intended Purpose |
|---|---|---|
| Fiber arrangement | Place fibers side by side | Establish the ribbon layout |
| Formation of subunits | Apply the first coating material around fiber groups | Keep groups of two or more fibers together as subunits |
| Bonding at intervals | Apply the second material between adjacent subunits | Join subunits at spaced points |
| Wet-on-wet bonding interface | Deposit bonds while the subunit coating remains uncured | Allow materials to form a diffusion zone |
| Joint curing step | Set the coating and bonds together in one step | Cure the assembled ribbon structure |
Main Production Line Stages And Process Controls
The fiber ribbon production stages proceed in a defined order. Workers arrange fibers into subunits, apply a subunit coating, add intermittent bonds between adjacent subunits, and then cure both together. Optical fiber coating application and bond placement must match the ribbon design.
Example designs specify gaps of 5 to 100 micrometers between subunits. Example intermittent bond spacing extends from 10 to 1,000 millimeters. Bond deposits may have a diamond-like outline with narrow ends and a wider center. These are disclosed examples, not fixed settings for every production line.
Ribbon manufacturing process control depends on the chosen material selection, bond layout, and curing method. The source material does not specify line speeds, curing temperatures, or inspection intervals, so these values must not be assumed.
Materials, Bond Design, And Ribbon Flexibility
Ribbon behavior during cable making and splicing depends on material choice and bond layout. Coatings protect each fiber while permitting the subunits to flex as intended.
Choose Compatible Coating And Bonding Materials
Because subunit coatings and ribbon bonding materials serve separate roles, they do not have to share the same formula. Resins that mix or remain at least partly soluble can form a gradual interface. Lower coating viscosity may also encourage intermixing.
A diffusion zone forms at this interface, with properties that change gradually. Differences in colour, stiffness, surface friction, tear strength, or stretch may occur within this zone. The disclosed thickness range is 2 to 50 micrometers, while 5 to 15 micrometers is given as a narrower range.
Manage Bond Placement, Spacing, And Geometry
Bond spacing controls where fiber subunits stay connected and where they can move freely. An intermittent bond layout creates unconnected spans separating the bond points. Intersecting convex and concave curves create the saddle shape used on some bond surfaces.
Balance Ribbon Flexibility With Fiber Organization
Unbonded spans allow the ribbon to shift from a flat layout into a rolled, curled, or folded shape. During cable installation, a flexible fiber ribbon can bend without disrupting the fiber organization needed for splicing.
Quality Checks For Consistent Ribbon Production
Reliable fiber ribbon quality checks measure defined features rather than relying on assumed pass limits. Design factors named in the patent include the spacing of bonds, subunit gaps, diffusion-zone thickness, and bond shape. The patent does not, however, define inspection methods or acceptance limits.
Inspect Bond Continuity And Subunit Alignment
Check that intermittent bonds connect adjacent subunits at planned locations and leave unbonded lengths between connections. Review subunit alignment and gaps because shifts can affect ribbon shape and bond geometry.
Evaluate Ribbon Flexibility And Rollability
To evaluate ribbon rollability, observe whether it bends and gathers while keeping fibers in their original order. Throughout the ribbon design, compare bond spacing and flexibility. Treat these comparisons as design checks rather than universal production tolerances.
Confirm Fiber Identification And Ribbon Configuration
Use fiber color coding to check the position of each fiber. Blue, orange, green, brown, slate, white, red, black, yellow, violet, rose, and aqua make up a common 12-color sequence. For ribbons containing more than 12 fibers, this sequence may be repeated.
Applications, Cable Integration, And Splicing Benefits
Intermittently bonded ribbons can roll inside a cable, enabling more fibers to fit into a compact design. Prysmian says FlexRibbon supports high-density ribbon cable designs, smaller diameters, and improved fiber duct utilization.
Enable High-Density Cable Designs And Better Duct Utilization
For indoor, outdoor, and indoor/outdoor applications, Prysmian offers FusionLink and MassLink with FlexRibbon. Dry water blocking is used in FusionLink, which comes with either 250 μm or 200 μm ribbon. EcoSpan aerial cable supports spans of up to 300 feet under NESC Heavy loading conditions. FlexDrop is a small-diameter outdoor option that accommodates up to two 12-fiber ribbons.
Enable Mass-Fusion Splicing And Faster Deployment
Mass-fusion splicing connects several ribbon fibers in a single operation, often 12 at once. This approach may shorten splice time where ribbon routes are compatible. When connecting to loose-tube cable, technicians separate ribbon fibers and individually splice them with a single-fiber splicer.
Consider Indoor, Outdoor, Access, And Broadband Uses
Applications for ribbon cable include point-to-point networks, indoor FTTH systems, MTP wiring-box links, and urban trunk routes. Selecting indoor and outdoor fiber cable for each route helps align cable construction with the needs of buildings, aerial runs, and underground installations.
Final Conclusions
An intermittent bonded ribbon line guide covers fiber layout, bond placement, curing, and inspection. The result is a flexible optical fiber ribbon that remains orderly during handling yet can roll or fold into compact cable designs.
In this process, bonds are placed before the subunit coating cures. Before they cure together, the materials develop a diffusion zone. Careful control throughout the process supports reliable fiber cable manufacturing.
Flexible ribbons also facilitate mass-fusion ribbon splicing, allowing crews to join multiple fibers at once. Prysmian describes FlexRibbon in various cable designs, including compact configurations containing up to 6,912 fibers.
For manufacturers and network planners, the priority is to balance fiber alignment, bond strength, and rollability. This balance may make cable packaging easier while ensuring ribbons remain prepared for efficient installation and splicing.
